6-Port Gigabit Switch with 4-Port PoE provides the seamless network connection. It integrates 1000Mbps Gigabit Ethernet and 10/100Mbps Fast Ethernet network capabilities
- 6 Gigabit Ports PoE Switch with 4-Port PoE ports
- Support Smart PoE Watchdog function
- Port 1 supports 802.3bt 60W Hi PoE
- Supports 250meters Long-Range PoE transmit
- Supports PoE power up to 30W for Port 2-8
- Supports PoE IEEE 802.3af/at/bt compliant PDs
- Internal power adapter supply 65W output power
- Support Port VLAN(Port isolation)
- LED indicators for LINK/ACT, Power, PoE Status, 100/1000Mbps
- 2K entry MAC address table with auto-learning and auto-aging
Data sheet
- Mac Address Table
- 2K
- Packet Buffer Memory
- 1Mb
- Temperature Range
- Working Temperature: -10°C~55°C Storage temperature : -40°C~70°C
- Dimensions
- 190mm*130mm*35mm
- Interface
- 6 1000M RJ45 ports
- Fan Quantity
- Fanless
- Exchange Capacity
- 12G
- Jumbo Frame
- 10240 Bytes
- Power Budget
- 65W
- Internal Power Supply
- AC 110~240V 50/60HZ
- PoE Ports (RJ45)
- Standard: 802.3 af/at/bt compliant PoE Ports: Port1- Port4 Power Supply: 65W
- Packet Forwarding Rate
- 7.5Mpps
- Transmission Method
- Store-And-Forward
- Protection Level
- Lightning protection 6KV 6KV ESD Contact discharge
- Advanced Functions
- Priority Function Mac Address Auto-Learning And Auto-Aging Store and forward IEEE 802.3x flow control for Full-duplex Mode Backpressure for Half-duplex Mode
